Cards that catch the light

Move over a piece and its card tilts toward your pointer, with a soft light under it that follows.

Live demo

Blossom Ginger Jar$164
Poppy Plate$54
Slipware Dish$68

Reduced motion: The cards don't tilt, and the light is where the pointer is, without the spring. It still comes on and goes off.

Beside Wardic

Motion's version hears the pointer through the card's onPointerMove, skipping a finger by its pointerType, and eases it back with onHoverEnd. Solid 2 hears it through the card's ward, when("hover") with the point and the card, and when("hoverEnd"); Solid 1 through onHoverStart and onHoverEnd and the element's pointermove. The springs and transforms are the same, and the light's place is a custom property in both, though Motion's style type doesn't name custom properties: its version casts.

The code

examples/spotlight/Demo.tsx

"use client"
import { PRODUCTS } from "@wardic/example-storefront-shared/catalog"
import { formatPrice } from "@wardic/example-storefront-shared/format"
import { photoOf, srcsetOf } from "@wardic/example-storefront-shared/images"
import type { Product } from "@wardic/example-storefront-shared/server"
import { type MotionStyle, motion, useMotionValue, useReducedMotionConfig, useSpring, useTransform } from "motion/react"
import type { PointerEvent } from "react"

const SHELF = PRODUCTS.filter((product) => ["poppy-plate", "blossom-jar", "slip-dish"].includes(product.id))

/** How far a card tilts toward the pointer at its edge, in degrees. */
const TILT = 8

// Under the pointer the card's light comes on: a custom property the stylesheet's glow reads.
const lighting = {
  rest: { "--light": 0 },
  lit: { "--light": 1 },
} as const

export default function Spotlight() {
  return (
    <ul className="spot-grid">
      {SHELF.map((product) => (
        <SpotCard key={product.id} product={product} />
      ))}
    </ul>
  )
}

function SpotCard({ product }: { readonly product: Product }) {
  // The system's setting, or the header's switch (`MotionConfig`).
  const reduced = useReducedMotionConfig()
  // Where the pointer is over the card, from -1 to 1 across and down: 0, 0 at its centre.
  const across = useMotionValue(0)
  const down = useMotionValue(0)
  const springAcross = useSpring(across, { stiffness: 260, damping: 22 })
  const springDown = useSpring(down, { stiffness: 260, damping: 22 })
  // The card turns toward the pointer; the light sits under it. Under reduced motion, no tilt.
  const tilt = (degrees: number) => (at: number) => {
    if (reduced) return 0
    return at * degrees
  }
  const rotateY = useTransform(springAcross, tilt(TILT))
  const rotateX = useTransform(springDown, tilt(-TILT))
  const lightX = useTransform(springAcross, [-1, 1], ["0%", "100%"])
  const lightY = useTransform(springDown, [-1, 1], ["0%", "100%"])

  // The pointer over the card places the light and the tilt; when it leaves, the card eases back
  // flat. A finger's pointer moves too, but touch never hovers: it moves nothing.
  const place = (event: PointerEvent<HTMLElement>) => {
    if (event.pointerType === "touch") return
    const box = event.currentTarget.getBoundingClientRect()
    const atAcross = ((event.clientX - box.left) / box.width) * 2 - 1
    const atDown = ((event.clientY - box.top) / box.height) * 2 - 1
    across.set(atAcross)
    down.set(atDown)
    // Under reduced motion the light doesn't glide either: it's where the pointer is.
    if (reduced) {
      springAcross.jump(atAcross)
      springDown.jump(atDown)
    }
  }
  const reset = () => {
    across.set(0)
    down.set(0)
  }

  const photo = photoOf(product.id)
  return (
    <li>
      <motion.article
        className="spot-card"
        variants={lighting}
        initial="rest"
        animate="rest"
        whileHover="lit"
        onPointerMove={place}
        onHoverEnd={reset}
        // Motion sets a custom property from a motion value, but its style type doesn't name them.
        style={{ rotateX, rotateY, "--light-x": lightX, "--light-y": lightY } as MotionStyle}
      >
        <div className="photo">
          <img src={photo.small} srcSet={srcsetOf(photo)} sizes="(max-width: 640px) 100vw, 240px" width={photo.width} height={photo.height} alt={product.name} />
        </div>
        <div className="line">
          <span className="name">{product.name}</span>
          <span className="price">{formatPrice(product.price)}</span>
        </div>
      </motion.article>
    </li>
  )
}
